Aug 27, 2015 Used- Manton Gaulin Homogenizer, Model 600-KF6-3PS, 304 Stainless steel. Approximate 600 gallons per hour, 3000 psi maximum. Two stage manual homogenizing valve assembly, triple plunger. Perry Videx offers used Homogenizer, Homogenizer, used equipment. Perry Videx offers used Homogenizer, Homogenizer, used equipment. 15 GPH @ 8000 PSI Manton Gaulin Lab Sized Homogenizer. Stock #M3890-033. Used Manton Gaulin model 15M8TA lab sized homogenizer. Design pressure 8000 psi. Serial #6-86-10104.
High efficiency SAMRO SRH6000-40 manton gaulin homogenizer:
Types of Homogenizer
- 1.Manual Operating Homogenizer
Two- stage homogenizer system with manual pressure adjustment is easy to use. It is your economic choice.
- 2.Hydraulic Operating Homogenizer
The hydraulic control system is developed to adjust the homogenizer pressure, and it is easy to upgrade to remote control system by changing to Proportional valves.
- 3.Pneumatic Operating Homogenizer
The pneumatic control system is developed for the homogenizer, and it is easy to upgrade to remote control.
- 4.Large Capacity Homogenizer
This machine has five plungers with the maximum flow reaching 30000L/H. The hydraulic end adopts the split structure which facilitates assembly and disassembly. The pressure adjustment can adopt manual or hydraulic mode.
- 5.Laboratory Homogenizer
Capacity: 60L/H Max Pressure</=70MPa
Minimum Sample Volume: 200ml
Two-stage Homogenizing
Colloid Grind Conveyer pump High pressure pump
| NO. | Machine | Piston | Working | MAX Working | Continual | Power | Weight | Size |
| Model | radix | rate | Pressure | Working | KW | Kg | L×W×H | |
| (Liters/Hr) | (Bar)MPa | Pressure | M | |||||
| (Bar) | ||||||||
| 1 | SRH60-70 | 1 | 60 | 70 | 0-56 | 3 | 270 | 0.7×0.4×1.3 |
| 2 | SRH250-70 | 3 | 250 | 70 | 0-56 | 5.5 | 700 | 1.2×0.8×1.0 |
| 3 | SRH500-35/45/70 | 3 | 500 | 35/45/70 | 0-28/36/56 | 5.5/7.5/11 | 700/750/800 | 1.2×0.8×1.0 |
| 4 | SRH1000-35/45 | 3 | 1000 | 35/45 | 0-28/36 | 11or15 | 800/850 | 1.2×0.8×1.3 |
| 5 | SRH1000-70 | 3 | 1000 | 70 | 0-56 | 22 | 1500 | 1.2×0.9×1.4 |
| 6 | SRH1500-30/60 | 3 | 1500 | 30/60 | 0-24/48 | 15/30 | 850/1800 | 1.2×0.8×1.3 |
| 7 | SRH1500-90 | 3 | 1500 | 90 | 0-72 | 45 | 2800 | 1.6×1.1×1.6 |
| 8 | SRH2000-25/30 | 3 | 2000 | 25/30 | 0-20/24 | 15/22 | 1500 | 1.2×0.9×1.4 |
| 9 | SRH2000-40 | 3 | 2000 | 40/45 | 0-32 | 30 | 1800 | 1.3×0.9×1.5 |
| 10 | SRH2000-70 | 3 | 2000 | 70 | 0-56 | 45 | 2800 | 1.6×1.1×1.6 |
| 11 | SRH2500-40 | 3 | 2500 | 40 | 0-32 | 37 | 1800 | 1.2×0.8×1.4 |
| 12 | SRH3000-25/30 | 3 | 3000 | 25/30 | 0-20/24 | 30 | 1600/1800 | 1.3×0.9×1.5 |
| 13 | SRH3000-40 | 3 | 3000 | 40 | 0-32 | 37 | 1800 | 1.7×1.1×1.5 |
| 14 | SRH3000-55 | 3 | 3000 | 55 | 0-44 | 55 | 2800 | 1.6×1.1×1.6 |
| 15 | SRH3000-70 | 4 | 3000 | 70 | 0-56 | 75 | 3000 | 1.7×1.5×1.3 |
| 16 | SRH3500-40 | 3 | 3500 | 40 | 0-32 | 45 | 2800 | 1.6×1.1×1.6 |
| 17 | SRH3500-50 | 3 | 3500 | 50 | 0-40 | 55 | 2800 | 1.6×1.1×1.6 |
| 18 | SRH4000-25/30 | 3 | 4000 | 25/30 | 20/24 | 37/40 | 1800 | 1.7×1.1×1.5 |
| 19 | SRH4000-40 | 3 | 4000 | 40 | 0-32 | 55 | 2800 | 1.6×1.1×1.6 |
| 20 | SRH4000-60 | 3 or 4 | 4000 | 60 | 0-48 | 75 | 3000 | 1.7×1.5×1.3 |
| 21 | SRH4000-70 | 4 | 4000 | 70 | 0-56 | 90 | 3000 | 1.7×1.5×1.3 |
| 22 | SRH5000-25/30 | 3 | 5000 | 30 | 0-20/24 | 45/55 | 2800 | 2.3×1.1×1.4 |
| 23 | SRH5000-45 | 4 | 5000 | 45 | 36 | 75 | 4000 | 1.7×1.5×1.3 |
| 24 | SRH5000-70 | 4 | 5000 | 70 | 56 | 110 | 4500 | 1.8×1.5×1.4 |
| 25 | SRH6000-25/30 | 3 or 4 | 6000 | 25/30 | 0-20/24 | 55/75 | 4000 | 1.7×1.5×1.3 |
| 26 | SRH6000-40 | 4 | 6000 | 40 | 0-32 | 75 | 4500 | 1.7×1.5×1.3 |
| 27 | SRH6000-55 | 4 | 6000 | 55 | 0-44 | 110 | 5000 | 1.8×1.5×1.4 |
| 28 | SRH7000-25/35 | 3 or 4 | 7000 | 25/35 | 20/28 | 55/75 | 4000 | 1.7×1.5×1.3 |
| 29 | SRH7500-30 | 4 | 7000 | 30 | 0-24 | 75 | 4500 | 1.7×1.5×1.3 |
| 30 | SRH8000-25/30 | 3 or 4 | 8000 | 25/30 | 0-20/24 | 75 | 4000 | 1.7×1.5×1.3 |
| 31 | SRH8000-40 | 4 | 8000 | 40 | 0-32 | 110 | 5000 | 1.8×1.5×1.4 |
| 32 | SRH10000-25 | 4 | 10000 | 25 | 0-20 | 90 | 4500 | 1.8×1.5×1.4 |
| 33 | SRH10000-35 | 4 | 10000 | 35 | 0-28 | 110 | 5000 | 1.8×1.5×1.4 |
| 34 | SRH10000-40 | 4 | 10000 | 40 | 0-32 | 132 | 5000 | 2.2×1.6×1.4 |
| 35 | SRH10000-45 | 4 | 10000 | 45 | 0-36 | 132 | 5000 | 2.2×1.6×1.4 |
| 36 | SRH12000-30 | 4 | 12000 | 30 | 0-24 | 110 | 4500 | 1.8×1.5×1.4 |
| 37 | SRH12000-40 | 4 | 12000 | 40 | 0-32 | 132 | 5000 | 2.2×1.6×1.4 |
| 38 | SRH14000-30 | 4 | 14000 | 30 | 0-24 | 132 | 5000 | 2.2×1.6×1.4 |
| 39 | SRH15000-23 | 4 | 15000 | 23 | 0-18 | 110 | 5000 | 2.2×1.6×1.4 |
| 40 | SRH16000-40 | 4 | 16000 | 40 | 0-32 | 200 | 5500 | 2.2×1.8×1.4 |
| 41 | SRTH20000-30 | 4 | 20000 | 30 | 0-24 | 200 | 5500 | 2.2×1.8×1.4 |
We pack all our machine in wooden box. It's very stable and safe.
1. If you have special requst, please kindly let us know. We will try our best to meet your demand.
2. We provide you free service of one year (under the normal operation). The additional fee (the tickets, the fee of living and eating for our engineer, etc) shall be charged if you need overseas service.
Samro homogenizer technology dates back to 1980, when China’s first 60MPa homogenizer, to fill the gap, and won the second prize of Shanghai Science and Technology and other six awards. More than twenty years, the application technology development path the deer take, aiming at the international advanced technology, the pursuit of high quality, efficient, durable, worry the market demand careful cultivation. Products to achieve nationwide coverage. Import substitution, the world’s goals. Our company has won free deer homogenizer fairs abroad, the national brand-name industry, Shanghai Science and Technology Festival logo products, the twenty-eighth International Business Award and other honors: in 2001 the French Technology Quality Supervision and Evaluation Committee as a “quality product” and “China entered the WTO Products” in 2003, was named “Shanghai patent pilot unit”, has won the “China Food and Packaging Machinery Industry Association, Shanghai Food Association and council member.
